Our product boasts exceptional environmental adaptability, featuring an IP54 or higher protection rating that enables it to easily withstand various harsh weather conditions such as extreme temperatures, salt spray, and humidity. Whether deployed in scorching heat, freezing cold regions, coastal areas with high salt spray, or rainy and humid environments, it can operate stably. Meanwhile, it supports 24/7 uninterrupted operation, effectively increasing operational hours, reducing downtime losses caused by environmental factors, and lowering long-term maintenance costs.
Main Parameter
| Model | KY-DC 07WD |
KY-DC-15WD | KY-DC 20WD |
KY-DC 30WD |
KY-DC 40WD |
| Output Power | 7KW | 15KW | 20KW | 30KW | 40KW |
| Output Current | 20A | 37A | 60A | 100A | 133A |
| Output Voltage | 200-750V(200-1000V optional) | ||||
| Input.Connection | L+N+PE | 3P+N+PE | |||
| Input Current | 32A | 25A | 32A | 45A | 64A |
| Input voltage | 90-265V | 260-475V | |||
| Frequency | 50/60Hz | ||||
| Power Factor | >0.99 @rated voltage | ||||
| Efficiency | 95% | ||||
| Display | 5 inch Color display | ||||
| Dimension(cm) | 42*22*65 | 50*23*70 | 60*27*83 | ||
| Weight | 20KG | 30KG | 44KG | 56KG | 70KG |
| Operating Temperature | -20°C to+50°C | ||||
| Altitude | 2000M | ||||
| IPLEVEL | IP54 | ||||
| Working Relative Humidity |
RH≤95% | ||||
| Input cable length | 0M(Customization Acceptable) | ||||
| Gun cable Length | 5M(Customization Acceptable) | ||||
| Connector type | CCS1 CCS2 CHADEMO GBT | ||||
| Charging protocol | GBT27930/CHADEMO 2.0/DIN 70121/OCPP 1.6(JSON)/ISO 15118 | ||||
The exclusive intelligent temperature control system ensures the charger's efficient operation, meeting customers' core demands for charging efficiency. Adopting a design that combines liquid-cooled charging gun cables with independent module heat dissipation, the system fundamentally solves heat dissipation challenges in high-temperature environments. This guarantees that even during hot summer months or high-load operational scenarios, the charger can maintain continuous high-power output, eliminating issues such as current interruption and power reduction.
About Us
Zhejiang Sinray Electronics Co. , Ltd. is one of the leading factory which specialized in the research and development and sales of new energy EV charging station, AC DC charge piles. We build trust-based partnerships with our clients that reflect our team's core values.
Always adhering to the "quality, integrity, pragmatic, enterprising, service" business philosophy.
Relying on science and technology, constantly improve the technical content of the products sold.
Strict quality assurance system and perfect management system, quality product after-sales service is our foothold.
Hot Tags: dc rapid charger, China dc rapid charger manufacturers, suppliers, factory, 40KW EV Charger, dc ev charger for alfa romeo giulia hybrid, dc ev charger for citro n c3 aircross electric, dc ev charger for koenigsegg jesko hybrid, dc ev charger for rolls royce dawn electric, DC Fast Car Charger
