(1) The AC power outlet must match the AC power plug of the charger.
(2) The AC voltage should be relatively stable, and the change should not exceed the range of 220V±10%.
(3) Charging operation procedure: a, open the power lock switch of the vehicle b, the charging plug and the body charging socket c, the power plug and the mains socket are connected.
(4) After the charger is connected to the power supply, the power indicator lights up when the wiring is correct, and the 1-30A charging current indicator lights up for one and two constant charges. More than 10 hours is better when the charging time is in a state of power loss.
(5) The charging process changes as follows: the first stage of constant current 25A charging for about 6 hours, the second stage of constant voltage charging for about 3 hours, and finally enter the floating charging stage, at this time, the floating charging light will be on, the charging current indicator will only light up 1-2, and the fan will stop rotating. The wrapping light is on and enters the floating charging stage, indicating that the battery is sufficient.
(6) After the battery is fully charged, or any need to shut down, the power supply of the electrical input must be disconnected first, and then the connection between the charger and the battery must be disconnected.
